Hydrous Sodium Aluminosilicate • Natural Clinoptilolite • Zeolite Granules and Powders

TYPICAL PROPERTIES:

TYPICAL CHEMICAL ANALYSIS

MAJOR EXCHANGABLE CATIONS

1. PRODUCT IDENTIFICATION

• PRODUCT: ATD/Natural Clinoptilolite Zeolite
• CHEMICAL NAME: Potassium Sodium Magnesium Calcium Aluminosilicate Mineral
• SYNONYMS: Zeolite, Clinoptilolite
• US DEPARTMENT OF LABOR OMB NO.: 1218-0072

2. COMPANY IDENTIFICATION

• COMPANY NAME: Synthetic Grass Warehouse
• MAILING ADDRESS: 1400 South Daly Street • Anaheim, California 92806
• PHONE NUMBER: 800.730.2675
• WEBSITE: www.turfdeodorizer.com

3. PHYSICAL DATA

• COLOR AND ODOR: Off white, odorless
• SPECIFIC GRAVITY: 1.5 - 1.7
• SOLUBILITY IN WATER: 0
• VAPOR PRESSURE: Not applicable
• EVAPORATION RATE: Not applicable
• BOILING POINT: Not applicable
• FREEZING POINT: Not applicable
• MELTING POINT: 1800 F

4. HEALTH HAZARD INFORMATION

• EYE CONTACT: May cause irritation
• SKIN CONTACT: May cause irritation
• INHALATION: Causes irritation
• INGESTION: No hazards known or suspected
• CHRONIC HAZARDS: No known hazards, contains no detectable crystalline silica, not listed by OSHA, NTP, or IARC as a carcinogen
• SYMPTOMS OF EXPOSURE: Coughing and irritation of respiratory tract

5. EXPOSURE CONTROL MEASURES

• RESPIRATORY PROTECTION: Use NIOSH approved dust mask or respirator where dust occurs
• GLOVES: Plastic, rubber, or cotton
• EYE PROTECTION: Safety goggles, or chemical goggles
• OTHER PROTECTIVE EQUIPMENT: Not applicable
• PERSONAL HYGIENE: Avoid breathing dust
• ENGINEERING CONTROL: Use with adequate ventilation

6. FIRST AID MEASURES

• SWALLOWING: If ingested in large quantities, contact physician to induce vomiting
• SKIN CONTACT: Rinse with water if irritation ensues
• INHALATION: : Remove the person to fresh air, rinse mouth and nasal passages with fresh water. Seek medical attention if irritation persists
• EYE CONTACT: Check for and remove contact lenses. Flush eyes with water for 15 minutes. Seek medical attention if irritation persists

7. FIRE AND EXPLOSION DATA

• FLASH POINT: Not applicable
• FLAMMABLE LIMITS: Not applicable
• FIRE EXTINGUISHING MEDIA: Not applicable
• SPECIAL FIRE FIGHTING PROCEDURES: Non combustible
• UNUSUAL FIRE AND EXPLOSION HAZARDS: None

8. REACTIVITY DATA

• STABILITY: Stable
• CONDITIONS TO AVOID: Not applicable
• INCOMPATIBILITY (Materials to Avoid): None

9. SAFE HANDLING AND USE

• STEPS TO BE TAKEN IN CASE MATERIAL IS SPILLED OR RELEASED: : Physical cleanup is required only to prevent sediment to surface water courses, depending on particle size of the product - no known environmental hazards
• WASTE DISPOSAL METHOD: Spills should be cleaned up in a manner that minimizes the generation of dust as a potential nuisance, or may be dispersed of in landfill according to local, state, and federal regulations
• PRECAUTIONS WHEN HANDLING AND STORING: Avoid breathing dust, may irritate the respiratory tract
• OTHER PRECAUTIONS: None

10. ECOLOGICAL CONSIDERATIONS

• WATERFOWL TOXICITY: Not Applicable
• AQUATIC TOXICITY: Not Applicable
• FOOD CHAIN CONCENTRATION POTENTIAL: Not Applicable
• BIOCHEMICAL OXYGEN DEMAND: Not Applicable
• ATMOSPHERIC: Contain no ozone depleting substances

11. TRANSPORTATION INFORMATION

• PROPER SHIPPING NAME: Non-Hazardous for Transport
• IATA HAZARD CLASS/PACKAGING GROUP: Not Regulated
• DOT HAZARD CLASS/PACKAGING GROUP: Not Regulated
• IMDG HAZARD CLASS: Not Regulated
• REFERENCE: Not Applicable RID/ADR
• DANGEROUS GOODS CODE: Not Regulated
• UN/NA IDENTIFICATION NUMBER:None
• UN TDG CLASS/PACKAGING GROUP: Not Regulated
• LABEL: None Required
• HAZARD IDENTIFICATION NUMBER (HIN): None

12. REGULATORY INFORMATION

• CALIFORNIA PROP 65: : There are no chemicals present in product known to the state of California to cause cancer or reproductive toxicity
• CPR (Canadian Controlled Products Regulations): This product has been classified in accordance with the hazard criteria of the CPR and the MSDS contains all the information required by the CPR. WHMIS Classification: Not Controlled
• DLS/NDSL (Canadian Domestic Substances List / Non-Domestic Substance List): Components of this product identified by CAS number are not listed on the DSL or NDSL, or are otherwise in compliance with the New Substances Notifications (NSN) regulations
• It is recommended that all recipients of this MSDS become familiar with and understand any hazards associated with this product. This information should then be made available to employees and customers who may come in contact with this material.

ZEOLITE-BASED BINDER FOR SOLIDIFICATION/STABILIZATION OF INDUSTRIAL HAZARDOUS WASTE

DESCRIPTION

A zeolite-based binding material for solidification/stabalization of industrial hazardous waste has been developed. This binding material will quickly solidify the hazardous waste, physically and chemically absorb the hazardous ions, and stabilize them by substitution in hydration products.

ADVANTAGES

A zeolite-based binding material has the following desirable characteristics:

• Stabilizing heavy metal ions, e.g. cadmium, zinc, mercury, etc., and radioactive ions, e.g. strontium, cesium, etc. in hazardous waste;
• Quick setting solidification (setting time in the range of 10-30 minutes);
• Sufficient strength for solidified forms (compressive strength in the range of 7-15 Mpa);
• Cost effective

UTILIZATION

The zeolite-based binding material can be manufactured with commercially available raw materials, existing cement mixing equipment and low energy cost processes.

CONCRETE ENCAPSULATION

The use of zeolite as a binding material in the formulation of hazardous waste encapsulating concrete capitalizes on the unique properties of high porosity, surface area, and exchange capacity as well as its pozzolanic activity. Zeolites are alumino-silicate minerals with a three dimensional porous molecular framework. The excess net negative charge imbalance gives them a high cation exchange capacity. The regular void spaces in the lattice allow molecular sieving and capturing based on size and charge. The porosity creates a large effective surface area for adsorption. The combined large surface area and charge character import pozzolanic activity to the mineral grains by improving hydraulic cementing properties while increasing buffering capability and corrosion resistance to resulting concrete.

STABILIZATION PROCESS

• Heavy metals such as Pb, Cd, Zn, Cu, Ag, and Hg are trapped by ion exchange
• Radioactive cations, Cs and Sr, are trapped by ion exchange
• Other mobile metal wastes, including As, U, Cr, and Mo may be immobilized by hydrogen bonding of oxyanions and physically encapsulated
• Volatile organic compounds may be captured by molecular sieving into the pore structure
• Non-volatile organics are adsorbed onto the large surface area of the zeolite grains

SOLIDIFICATION AND ENCAPSULATION

Encapsulating zeolite concrete is made with zeolite as a portion of the aggregate. It is manufactured with a situation-specific formulation, but using common, commercially available raw materials, cement and admixtures and normal low cost, energy efficient concrete manufacturing processes.

The pozzolanic and buffering zeolite component not only traps, adsorbs and immobilizes contaminants, but also adds strength and corrosion resistance to the encapsulating zeolite concrete. The bound material is quickly solidified in the process to physically envelop the hazardous waste into a concrete block or aggregate. Sufficient compression strength (7-15 Mpa) is achieved after curing for some load bearing situations. In many cases, a useful product will result.

The encapsulated, stabilized product passes CGSB or TCLP leachate tests and can be safely stored without fear of contaminants being remobilized; a permanent remediation.

APPLICATIONS

• Oil and fuel contaminated soils
• Invert drilling cuttings (with or without brines)
• Flare pit remediation
• Heavy metals, lead paint residue
• Paint sludge
• Contaminated wood waste
